JL15 Series AC/DC current relay

Current type

Model

Rated current of the suction coil Ie( A)

Suction current adjustment range

Contact form

Connection mode

Note

DC

OR AC

JL 15 - / 01

JL 15 - / 11

JL 15 - S/ 01

JL 15 - S/ 11

1 . 5 , 2 . 2 , 5 , 10

15 , 20 , 30 , 40

60 , 80 , 100 , 150

250 , 300 , 400

600 , 800 , 1200

80 - 300 % Ie

Front wiring for boards under 60 A

80 A and above board back wiring or board front wiring

The relay contact forehead is 5A

JL 15 - / 02

JL 15 - / 22

JL 15 - S/ 22

JL 15 - S/ 22

120 - 400 % Ie

AC

JL 15 - F/ 01

JL 15 - F/ 11

120 - 400 % Ie

The return coefficient is 0.6-0.85

For 600 A's and 1200 A's,

When the setting current is greater than twice the rated current, a drop of 0.1 is allowed

Model

Rated current of the suction coil（A)

Connection mode

After the board（mm)

Connection screw specifications

A

B

C

JL 15- / 01

JL 15- / 11

1 . 5 - 60

80 - 150

250

300 - 600

800 - 1200

Before the board

145

185

188

188

215

56

69

77

77

113

-

-

-

-

-

-

M 6

M 8

M 10

M 12

M 16

JL 15 - H/ 01

JL 15 - H/ 11

80 - 150

250

300 - 600

800 - 1200

After the board

160

170

175

185

69

77

77

113

164

167

167

170

M 8

M 10

M 12

M 16
